| Laser Model |
Crabs- 140x100 |
| Laser Type |
Co2 Laser |
| Laser Tube Type |
Co2 Glass Tube |
| Laser Power |
70 w - 150 w |
| Control System |
Dsp (High-Speed Usb Transfer) |
| Work Area |
1400x100mm |
| Sensitivity |
< 0.01 mm |
| Operation Temperature |
0 °C – 45°C |
| Resolution |
Advanced model 1200 DPI |
| Motion System |
Step Motor (Servo Motor System can be installed , optionally ) |
| Cooling System |
Water Chiller CW 5000- CW5200- CW6000 |
| Operating Voltage |
AC220V ±5% , 50/60Hz |
| Supported Formats |
CorelDraw, X2 thru X4, AutoCAD,AI, DXF, PLT, DST, DSB, BMP, GIF, JPG, PNG, MNG, ICO CUR, TIF, TGA, PCX, JBG, JP2, JPC, PGX, RAS, PNM, SKA, RAW |
| Operating System Software |
Windows Xp,Windows 7, Windows 8 |
| Applicable Materials: |
Wood,Plexi Glass, Paper ,Rubber, Melamin, Fiberglass Natural Coating, Mushroom, Tile, Leather, Fabric, Denim, Bamboo, Mdf, etc. |
| Applicable Industries: |
Advertising, Garment, Embroider, Fabric, Toy, Furniture, Reticule, Glove, Leather, Decoration, Gifts, Model, Electric Product, Rubber, Acrylic product, Bamboo, pressing and packaging industries, morever Middle Density Fiber Board and Non metal sheet precision cutting. |
